SIMRAD SX93 SONAR

The SIMRAD SX93 sonar is a low-frequency, high-definition, long-range sonar. It is specially designed for vessel where high-resolution combined with long-range is needed.

The SX93 sonar offers unique features, such as full-circle beam stabilization for easier fish detection and 11 difference from other sonars.

Main Features:
 - 360° omnidirectional sonar.

 -90° vertical tip mode.

 -20 to 30 KHz operational frequency.

 - Narrow beams.

 -Selectable beam width.

 -Hyperbolic FM.

 -Large dynamic range.

 -High definition.

 -Stabilized beams.

 -Dual beam operation.

 -Easy operation.

 -Store and recall sonar data.

 -Define your own user settings.

- Screen: 24inch (optional 17inch screen).

- Frequency: 20 - 30 kHz.

- Basic scale: 150 - 4500m.

- Target detection: 3000 - 4500m.

- Transducer size: 546mm (21.5'') x 382mm (15'').

- Tilt angle: +10° to -90° (no blind spots).

- Vertical opening angle: 7.1° ~ 14.8°

- Transducer Stabilization: Full Stabilization 360°+/-20°

- Power source: Processor: 230VAC/ 1 phase; Lifter: 220VAC/3 phase.

- Signal processing technology: digital.
